NoMachine 4.0 Player

No Machine 4.x NX Player

The No Machine NX player allows you to have a secure remote desktop even with a dial-up modem. With DSL or a cable modem connection, it comes close to physically being at the console. It is available for Linux, Windows, and MacOS.

This works on all of our servers except the SunOS 4.1.4 based server, eskimo.com. On Shellx and Scientific, choose the Gnome or KDE Desktop. On all of the newer machines the default desktop uses a compositing window manager which is not compatible with NX or X2Go. On these machines use Mate. To do this select custom session and fill in “mate-session” as the command to execute.

  1. Download the free 4.0 nx client / player from the No Machine website.
  2. The first time you start the 4.0 nx client / player, if there are no existing connections, you will see a screen like this. Click on the little computer with the ‘+’ symbol to add a computer.nx40s1
  3. Fill in the Name box with a Connection name such as “Eskimo” or “Shellx”. This is just a name for you to know where you are connecting.Select “ssh” for the protocol.Fill in the Host box with the fully qualified domain name such as “shellx.eskimo.com” or “debian.eskimo.com”.The port should be “22”. It should set this automatically when you select “ssh” as the protocol.After you’ve filled this in click on: Advancednx40s2
  4. You will now be asked how you want to authenticate. The server we are using here is based upon 3.5, so choose the second method, “Use the NoMachine login”. Do not check the “Use HTTP Proxy” box unless you actually must connect through an HTTP proxy server. We have not tested this functionality.nx40s3
  5. Click on Continue
  6. Click on: Connectnx40s5
  7. Type in your login and password.If you are on a non-shared secured computer, check the “Save this password in the configuration file” box.Click on: Oknx40s6
  8. Click on “<New virtual desktop or custom session>”.nx40s7
  9. For Shellx and Scientific, select either Gnome or KDE Desktop depending upon your preference.For other Linux shell servers select Custom Session. Specify the “Run the specified command” and fill in the command “mate-session” and select “Run the command in a virtual desktop.Mate is a fork of Gnome2 that is functionally identical.nx40s8
  10. The 4.0 player is not 100% reliable when connecting to 3.5 based servers. Sometimes you will get an error like the one below. This is only one of many possible errors.If it fails, just click OK and reselect the session and try to connect again .I have found it helpful to wait 2-3 seconds between selecting the session and connecting.nx40s9
  11. A successful connection will bring up a desktop. It will take several seconds and fade in. You will not get the big red and white “!M” like you did with NX 3.5 client.desktop
  12. Enjoy! To end the session and logout, click on your username in the upper right hand portion of the screen.
  13. If you don’t have a shell account here, now is an excellent time to find out what you’ve been missing! Click Here For a Free Two Week Trial.
